Explore Our Engraving and Milling Spindles Range

Spindle Finder
150
120
80
100
61.92

FEATURES

High precision

The thermal elongation of the spindle is less than 0.03mm, and the thermal elongation fluctuation is less than 0.002mm; Spindle core end face and cone hole runout ≤0.001mm, full speed section spindle vibration ≤ 0.8mm/s (customized up to 0.5mm/s), machining parts surface roughness up to Ra 0.05, widely used in steel, copper, aluminum and other types of mold and parts processing.

High rigidity

Reasonable shafting design and bearing configuration ensure high bearing rigidity during spindle processing.

Super seal construction

The whole series of products adopt the excellent labyrinth seal and the compatible design of the air curtain seal structure. After the sealing performance verification of nearly 100000 pieces in the market, it ensures that the external coolant, processing residual and other foreign matters can avoid entering the spindle under the condition of 0.15MPa air seal.

High efficiency

In order to deal with the complex product processing environment, the double winding electrical main group is specially developed. Low speed winding has the characteristics of high torque, suitable for coarse, re-cutting, large aperture drilling, tapping; High speed winding has the characteristics of low heating, high precision, high power and no attenuation, suitable for all kinds of conventional parts milling and high gloss processing. Customers can switch between high winding and low winding according to their requirements, to realize the improvement of product processing domain, machine upgrade and competitiveness.

Super long life broach mechanism

Equipped with Hozhi broach mechanism with independent intellectual property rights, the tool change life is more than 10 million times. In the whole life cycle, The Vibration of Hozhi broach mechanism is 30% higher than that of the traditional disc spring broach mechanism, and the vibration stability is always maintained at the highest level without late maintenance.

Super seal construction

The whole series of products adopt the excellent labyrinth seal and the compatible design of the air curtain seal structure. After the sealing performance verification of nearly 100,000 pieces in the market, it ensures that the external coolant, processing residual and other foreign matters can avoid entering the spindle under the condition of 0.15MPa air seal.

Double winding spindle

In order to deal with the complex product processing environment, the double winding electrical main group is specially developed. Low speed winding has the characteristics of high torque, suitable for coarse, re-cutting, large aperture drilling, tapping; High speed winding has the characteristics of low heating, high precision, high power and no attenuation, suitable for all kinds of conventional parts milling and high gloss processing. Customers can switch between high winding and low winding according to their requirements, to realize the improvement of product processing domain, machine upgrade and competitiveness.

APPLICATION

3C

3C

Jewelry

Jewelry

Medical / dental

Medical / dental

Aerospace

Aerospace

APPLICATION CASE

Discuss Your CNC Spindle or Motion Component Project

Share your machine type, machining process, performance targets or existing component specifications with Haozhi. Our technical team can support spindle selection, application matching, custom development and motion-component integration for new equipment and upgrade projects.
