DGZX-18015 Dual-Winding BBT40 Milling Spindle

The DGZX-18015 uses a double-winding motor to cover different speed and torque operating ranges. BBT40 tooling, hydraulic tool change and optional center cooling make it suitable for machining centers switching between stronger cuts and higher-speed finishing.
Diameter Φ180mm
Maximum speed 15000rpm
Torque(S1) 60.5Nm
Torque(S6-40%) 92Nm
Power(S1) 19kW
Power(S6-20%) 28.5kW
Request Now
DGZX-18015 Dual-Winding BBT40 Milling Spindle

INTRODUCTION

FEATURES

APPLICATION

FAQ

TECHNICAL DATA

ModelDGZX-18015/22-BBT
DiameterΦ180 mm
Tool interfaceBBT40
Bearings lubricationGrease
Motor systemDouble-winding asynchronous
Highest speed15,000 rpm / 18,000 rpm
Voltage380 V
Rated power (S1-100%)Y: 19 kW / Δ: 22 kW
Rated torque (S1-100%)Y: 60.5 N·m / Δ: 35 N·m
Rated power (S6-40%)Y: 28.5 kW / Δ: 33 kW
Rated torque (S6-40%)Y: 92 N·m / Δ: 52.5 N·m
Spindle coolantWater (recommended)
Tool outer coolant (Ring spray)Water / Oil / Oil mist / Air
Tool inner coolant (Center cooling)Water / Oil / Oil mist / Dry air
Tool changeHydraulic
Motor temperature sensorKTY84-130, PTC
Bearing temperature sensorOptional
EncoderSin/cos, 1Vpp
Tool clamping monitor sensor24V, PNP, Normally Open
Vibration sensorNot supported
Displacement sensorOptional
Weight90 ± 2 kg

DIMENSIONS
