DZDA-125-300/600-105/20-A26-A/A Tool Grinding Head

This single-arm head integrates an A63 tool interface with independent tilting and rotary axes. The tilting axis reaches 600 Nm, while water cooling, central dust blowing and high pull force support automated tool-grinding and laser-processing systems.
Request Now
DZDA-125-300/600-105/20-A26-A/A Tool Grinding Head

INTRODUCTION

FEATURES

APPLICATION

FAQ

TECHNICAL DATA

DZDA-125-300/600-105/20-A26-A/A
ParametersTilting AxisRotary Axis
Rated Torque (Nm)30030
Maximum Torque (Nm)60075
Rated Current (A)182.8
Maximum Current (A)367
Rated Speed (rpm)200240
Maximum Speed (rpm)200240
Voltage for Driver (V)220220
Rated Power (kW)60.75
Maximum Power (kW)121.88
Clamping Torque (Nm)≥500/
Clamping air Pressure (MPa)0.55-0.6/
Encoder (Renishaw Biss-C)26位26位
Rotation Angle (°)±110任意
Cooling Method水冷自冷
Positioning Accuracy (°)10±2
Repeatability Accuracy (°)±10±2
Taper End Face Runout (mm)≤0.001≤0.001
Taper Surface Runout (mm)≤0.001≤0.001
Center Blow Dust Pressure (MPa)0.5~0.6
Tool Holder InterfaceA63
Tool Release Reset Air Pressure (MPa)0.5~0.6
Pull Force (N)≥4500
Air Seal Pressure (MPa)0.2
Workpiece Load Capacity (kg)20
Total Machine Weight (kg)187
