DK-GF180A-T VNT Energy-Recovery Air Compressor

The DK-GF180A-T adds a VNT energy-recovery turbine to its two-stage compression system. It covers 15–245 g/s, reaches a 3.8 pressure ratio and is specified to improve maximum energy efficiency by 30% for fuel cell air supply.
Request Now
DK-GF180A-T VNT Energy-Recovery Air Compressor

INTRODUCTION

FEATURES

APPLICATION

FAQ

TECHNICAL DATA

Spindle ModelDK-GF180A-T
Structural formTwo stage compression+ Energy recovery+VNT
Flow range (g/s)15-245
Speed range (rpm)30000-95000
Voltage (VDC)450-750
Air compressor weight (kg)16.5
Temperature of the intake air (°C)-30~45
Type of BearingAir suspension bearing
Maximum compression ratio3.8
Max. motor power (kW)30
Maximum energy efficiency improvement30%
Start-stop life (times)300000
Controller weight (kg)7.3
Protection levelIP67

DIMENSIONS
