DK-GF150-3.0D Fuel Cell Air Compressor

The DK-GF150-3.0D combines a lower maximum flow of 190 g/s with a comparatively high 3.9 pressure ratio. Air-suspension bearings, speeds up to 95,000 rpm and IP67 protection support compact fuel cell installations that prioritize pressure capability.

Request Now
DK-GF150-3.0D Fuel Cell Air Compressor

INTRODUCTION

FEATURES

APPLICATION

FAQ

TECHNICAL DATA

Spindle ModelDK-GF150-3.0D
Structural formTwo-stage supercharging
Flow range (g/s)15–190
Speed range (rpm)30000–95000
Voltage (VDC)450–750
Air compressor weight (kg)15.2
Temperature of the intake air (°C)-30~45
Type of BearingAir suspension bearing
Maximum compression ratio3.9
Max. motor power (kW)30
Start-stop life (times)300000
Controller weight (kg)7.3
Protection levelIP67

DIMENSIONS
